DAOKI 5A MPPT Controlador de carga solar Placa de carga solar 1-100W 9-28V Módulo de carga de batería 9V 12V 18V 24V 300KHz con protección de conexión inversa

- Make sure this fitsby entering your model number. - MPPT 5A Solar Charging Board Suitable for 1W-100W 9V-28V 9V 12V 18V 24V solar panels to charge batteries, nickel-cadmium, nickel-metal hydride, lithium batteries (battery packs), wind turbines, solar street lights, etc. - High-quality switching power supply dedicated high-frequency low-resistance electrolytic capacitors (LOW ESR) are used at the input and output terminals to ensure output ripple. With thick radiator. - Input voltage: DC 8-28V Input DC voltage (disable AC input). - Output voltage: DC 5-26V stepless adjustable output. Output current: 5A maximum charging current. - Can charge 6V or 12 V batteries or 8.4V, 12.6V, 16.8V lithium batteries, 7.2V, 10.8V, 14.4V lithium iron phosphate batteries, 2-4 string lithium batteries, lithium iron phosphate charge management board. Description: User Manual Download: https://www.amazon.com/clouddrive/share/LFDgH37V8UcicD9tMgKzRHVfD70WUvKnzbyf1dkYUly Specification: Module properties: MPPT solar maximum power point tracking function, automatic intelligent charging management, low power consumption. Input voltage: DC 8-28V Input DC voltage (disable AC input). Output voltage: DC 5-26V stepless adjustable transmission. Output current: 5A max Charge indicator: Yes. The fast charging red light glows brightly, full of red, blue, and alternating lights. Full automatic stop. MPPT function: Yes. The lowest pressure difference: 1V. Ultra low dropout design is used to achieve low power consumption and higher conversion efficiency, professionally adapting solar panels. Operating temperature: Industrial grade (-40C to +85C). Load regulation: 1%. Voltage regulation rate: 0.5%. Conversion efficiency: Max: 93% / Peak: 95% Different lighting conditions are different. Charging method: automatic intelligent three-phase charging mode. Tracking solar power automatically adjusts the size of the charging current No-load current: 3mA. Input reverse protection: Yes. Output reverse protection: Yes. MPPT voltage: adjustable, Package Included: 1 x MPPT 5A Solar Charging Board 1 x 30cm/11.8inch 24AWG Power Wire
